Limestone Rod Mill

Limestone Rod Mill

Condition: New

Colour: as request

Power: Saving energy

Brand Name: Hongxing Machinery

Linner: Steel, rubber or slicon


limestone rod mill

Henan Hongxing Mining Machinery Co., Ltd. has always been committed to the production of mining products. Based on many years' experience, Henan Hongxing Mining Machinery has researched and developed new generation of rod mill products, such as limestone rod mill.

Henan Hongxing Mining Machinery adopts advanced controllable feeding and discharging technology, combines with the actual rod grinding machines and changes the traditional surface contact into the line contact so that the particle size is more uniform and the yield is higher. Hongxing limestone rod mill is widely used in the milling operations in refractory, chemical industry, metallurgy, glass and other industries which have relatively high requirements for the uniformity of the finished products. In recent years, the limestone rod mill is also widely used in the construction sand industry. The limestone rod mill is composed of the feeding part, cylinder, discharging part, bearing, transmission, foundation part and other components. There is a steel bar installed in the cylinder body of the limestone rod mill.

Limestone Rod Mill

Limestone Rod Mill

The new generation of limestone rod mill produced by Henan Hongxing Mining Machinery has the following process characteristics. First, this kind of limestone rod mill can save power, which can save more than 40% power compared with the old type of machine. The particle size of the products is uniform. Compared with the characteristics of products of the ball mill, the characteristics curve of products of the rod mill with open circuit is almost the same as the characteristics of the products of ball mill with closed circuit. Second, the discharging granularity is uniform with high yield.

Third, the discharging fineness is adjustable. The discharging fineness can be changed through simple adjustment. There is fineness control device and screening device in the machine, which can avoid overmilling phenomenon and prevent the unqualified products from mixing the finished products. The particle size characteristics of the products of rod mill are related to the situation of the crushing ores. Fourth, the limestone rod mill can be used for selective crushing with uniform particle size and little mudding role.

Hongxing limestone rod mill is your best choice. We win customers with good faith and capture the market with excellent quality.


Parameters type

Shell Specifications (mm)
Shell rotation speed
Feeding size
Discharging size
Processing capacity
Total weight
Diameter Length
MBS0918 900 1800 36-38 ≤25 0.833-0.147 0.62-3.2 18.5 5.9
MBS0924 900 2400 36 ≤25 0.833-0.147 0.81-4.3 22 6.7
MBS1224 1200 2400 36 ≤25 0.833-0.147 1.1-4.9 30 13.9
MBS1530 1500 3000 29.7 ≤25 0.833-0.147 2.4-7.5 75 19.8
MBS1830 1830 3000 25.4 ≤25 0.833-0.147 4.8-11.6 130 34.9
MBS2130 2100 3000 23.7 ≤25 0.833-0.147 14-35 155 46.5
MBS2136 2100 3600 23.7 ≤25 0.833-0.147 19-43 180 48.7
MBS2430 2400 3000 21 ≤50 0.833-0.147 25-65 245 59.7
MBS2736 2700 3600 20.7 ≤50 0.833-0.147 32-86 380 92.5
MBS2740 2700 4000 20.7 ≤50 0.833-0.147 32-92 400 95
MBS3245 3200 4500 18 ≤50 0.833-0.147 64-180 630 149
