Cone Crusher

Cone Crusher

Type: Tertiary Crusher

Production capacity: 12-1000t/h

Supply Ability: 20 Set/Sets per Month

Port: Qingdao,Tianjin, Shanghai or others

Materials: Iron ore, copper ore, gold ore, manganese ore, river stone, gravel, granite, basalt, mine ore, quartz, diabase, etc.(for hard stone)

sales@hxjq.com


Cone crusher is widely used for medium and fine crushing of all kinds of rocks with compressive strength under 350MPa in mining, cement industry, sand industry, metallurgy and other fields. China cone crusher is especially suitable for material with Mohs hardness within the range of 5-16, such as iron ore, non-ferrous metallic ore, granite, limestone, quartzite, sandstones, pebbles, etc.

Cone Crusher Types

Types of cone crusher: Symons cone crusher, secondary cone crusher, Hydraulic cone crusher, spring cone crusher, CS series high efficiency spring cone crusher, HPC Hydraulic cone crusher, HCS high efficiency hydraulic cone crusher, etc.

Cone Crusher Types

Symons Cone Crusher

Henan Hongxing Mining Machinery Co., Ltd. is a professional Symons cone crusher manufacturer and exporter in China. We are specialized in the production of Symons cone crusher. These products have been delivered to Europe, United States, Asia, the Middle East, Russia, Africa etc. We are expanding more cooperation partners all over the world.

Symons Cone Crusher

Secondary Cone Crusher

There are two types of rock crushers in actual production, that is, primary crusher and secondary crusher. Secondary crushers mainly handle rocks of smaller particle size. In recent years, with the rapid development of infrastructure projects, rock crushers have been applied in various fields and industries, such as mining, chemical industry, road construction, metallurgy, construction and so on.

Hydraulic Cone Crusher

Hydraulic Cone Crusher

HPC series hydraulic cone crusher designed by our company is a new type of cone crusher with international advanced level. Our hydraulic cone crusher greatly increases the production capacity and crushing efficiency; it is more suitable for the mining and construction industry than spring cone crusher and common hydraulic cone crusher. HPC series hydraulic cone crusher is the most ideal equipment for large-scale stone factory.

cone crusher

The spring system is the overload protection device which makes foreign materials go through the machine without causing any damage to the machine. The sealing modes are oil and water, which segregates the stone powder and lubricting system.

Hongxing Machinery is a professional cone crusher manufacturer, welcome customers from all over the world to visit our company.

Parameters type

Specification Model Diameter
of large
end of
crushing
 cone
(mm)
Max.feeding
size(mm)
Width of
discharge
opening
(mm)
Processing
capacity
(t/h)
Motor
power
(kw)
Total
weight
(t)
Dimensions
(L×W×H)
(mm)
Φ600 PYB600 600 65 12-25 40 8P   30 5 2234×1370×1675
PYD600 35 3-13 12-23 5.5 2234×1370×1675
Φ900 PYB900 900 115 15-50 50-90 8P   55 11.2 2692×1640×2350
PYZ900 60 5-20 20-65 11.2 2692×1640×2350
PYD900 50 3-13 15-50 11.3 2692×1640×2350
Φ1200 PYB1200 1200 145 20-50 110-168 8P   110 24.7 2790×1878×2844
PYZ1200 100 8-25 42-135 25 2790×1878×2844
PYD1200 50 3-15 18-105 25.3 2790×1878×2844
Φ1750 PYB1750 1750 215 25-50 180-360 8P   160 50.3 3910×2894×3809
PYZ1750 185 10-30 80-210 50.3 3910×2894×3809
PYD1750 85 5-13 60-180 50.2 3910×2894×3809
Φ2200 PYB2200 2200 300 30-60 420-700 8P   280-260 80 4622×3302×4470
PYZ2200 230 10-30 130-410 80 4622×3302×4470
PYD2200 100 5-15 80-200 81.4 4622×3302×4470
